Sale! View larger

Yttrium Fluoride (YF3) Powder

HTRE1159

New product

Yttrium Fluoride YF3 is applied in petroleum and environment protection catalysts, mischmetal, polishing powders and Rare Earth fertilizers. Heeger Materials (HM) provides Yttrium Fluoride YF3 at a competitive price. The purity and particle size can be customized.

More details

Inquiry

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Data sheet

MF YF3
MW 145.9
Purity 99.999%/99.99%/99.9%/99%
CAS 13709-49-4
Synonyms Yttrium Fluoride/YttriumFluorid/Fluorure De Yttrium/Fluoruro Del Ytrio

More info

Yttrium(III) fluoride is an inorganic chemical compound with the chemical formula YF3. It is not known naturally in 'pure' form.  HM stocks a wide variety of rare earth materials for use in electronics, petrochemical, metallurgy, machinery, energy, environmental protection, agriculture, and other fields. We also offer pure metals and compounds for R&D applications.

  • CAS: 13709-49-4
  • Molecular Formula: YF3
  • Purity: 99.9 %-99.99 %
  • Specification Model: - 40 mesh
  • EINECS No.:237-257-5
  • Chemical formula: YF3
  • Molar mass: 145.90 g mol−1
  • Appearance: white powder
  • Density: 4.01 g cm−3
  • Melting point: 1,387 °C (2,529 °F; 1,660 K)
  • Boiling point: 2,230 °C (4,050 °F; 2,500 K)
  • Solubility in water: insoluble
  • Solubility in acid: soluble
  • Refractive index (nD): 1.51 (500 nm)
  • Crystal structure: Orthorhombic, oP16

Yttrium Fluoride is widely applied in metallurgy, ceramics, glass, and electronics. High purity grades are the most important materials for tri-bands Rare Earth phosphors and, which are very effective microwave filters. Yttrium Fluoride also can be used for the production of metallic Yttrium, thin films, glasses, and ceramics. Yttrium is used in the production of a large variety of synthetic garnets, and Yttria is used to make Yttrium Iron Garnets, which are very effective microwave filters.

Specification

Grade 99.999% 99.99% 99.9% 99%
CHEMICAL COMPOSITION
Y2O3/TREO (% min.) 99.999 99.99 99.9 99
TREO (% min.) 77 77 77 77
Rare Earth Impurities ppm max. ppm max. % max. % max.
La2O3/TREO
CeO2/TREO
Pr6O11/TREO
Nd2O3/TREO
Sm2O3/TREO
Eu2O3/TREO
Gd2O3/TREO
Tb4O7/TREO
Dy2O3/TREO
Ho2O3/TREO
Er2O3/TREO
Tm2O3/TREO
Yb2O3/TREO
Lu2O3/TREO		 1
1
1
1
1
2
1
1
1
2
2
1
1
1		 30
30
10
30
5
5
5
10
10
20
20
5
20
5		 0.01
0.01
0.01
0.01
0.005
0.005
0.01
0.001
0.005
0.03
0.03
0.001
0.005
0.001		 0.03
0.03
0.03
0.03
0.03
0.03
0.1
0.05
0.05
0.3
0.3
0.03
0.03
0.03
Non-Rare Earth Impurities ppm max. ppm max. % max. % max.
Fe2O3
SiO2
CaO
Cl-
CuO
NiO
PbO
Na2O
K2O
MgO
Al2O3
TiO2
ThO2		 100
500
300
100
2
3
2
15
15
15
50
50
20		 300
600
500
300
5
5
10
15
15
15
50
50
20		 0.05
0.08
0.08
0.05		 0.06
0.1
0.1
0.1

Application

Yttrium(III) fluoride can be used for the production of metallic yttrium, thin films, glasses, and ceramics.
