Niobium Carbide Powder, NbC, CAS 12069-94-2
HMCP-1706
New product
Niobium Carbide (NbC) Powder is a black powder with a cubic crystal structure. It has a high melting point of 3500℃, which is widely used in refractory high-temperature materials. The purity and particle size can be tailored according to specific requirements.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Data sheet
| Purity | 99.5% |
| CAS | 12069-94-2 |
| Molecular Formula | NbC |
More info
Niobium Carbide (NbC) Powder is a metallic luster powder with high hardness, which is harder than corundum. Heeger Materials can provide high-quality Niobium Carbide (NbC) Powder at a competitive price.
- Formula: NbC
- Density: 7.6 g/cm3
- Melting point: 3500℃
- Microhardness: >23.5 GPa
- Molecular weight: 104.923 g/mol
- CAS: 12069-94-2
Niobium Carbide Powder Specifications
Product | Particle Size FSSS (μm) | Chemical Composition (%) | |||||||||||
Total Carbon | Free Carbon | Impurity (%max) | |||||||||||
Ta | W | Ti | Si | Na | Fe | O | N | K | Ca | ||||
HM-NbC-1 | 0.8-1.0 | 11-11.4 | ≤0.30 | 0.20 | 0.10 | 0.02 | 0.01 | 0.01 | 0.05 | 0.50 | 0.20 | 0.01 | 0.01 |
HM-NbC-2 | 1.0-1.5 | 11-11.4 | ≤0.30 | 0.20 | 0.10 | 0.02 | 0.01 | 0.01 | 0.05 | 0.50 | 0.20 | 0.01 | 0.01 |
HM-NbC-3 | 1.5-2.0 | 11-11.4 | ≤0.30 | 0.20 | 0.10 | 0.02 | 0.01 | 0.01 | 0.05 | 0.50 | 0.20 | 0.01 | 0.01 |
Niobium Carbide Powder Properties
Niobium Carbide (NbC) Powder is a high-hardness material with good chemical stability and high-temperature performance.
.jpg)
- Insoluble in hot and cold hydrochloric acid, sulfuric acid, nitric acid
- Soluble in hot hydrofluoric acid and nitric acid mixed solution.
- Stable at 1000-1100°C
- Oxidizing rapidly to niobium pentoxide above 1100°C
- Easily fused in compounds such as titanium carbide, zirconium carbide, and tungsten carbide, and together they produce a homogeneous solid solution mixture
Niobium Carbide Powder Applications
- Used as a hard alloy additive
- Used in producing wear-resistant films and semiconductor films
- Used to prepare carbide tool materials with excellent cutting performance
- Processed into purple artificial gemstones
Niobium Carbide Powder Storage and Packing
Niobium Carbide (NbC) Powder should be sealed and stored in a dry, cool environment with inactive anti-static packaging, avoiding being exposed to the air for a long time. The vacuum package is 100g, 500g, 1kg/bag, 50kg/drum, or as required.
