Tantalum Carbide Powder, TaC, CAS 12070-06-3

HMCP-1698

New product

Tantalum Carbide (TaC) Powder is a yellow-brown powder with a cubic crystal structure, which has high hardness, high melting point, and good high-temperature performance, and is mainly used as an additive for cemented carbide. Heeger Materials can provide the best Tantalum Carbide (TaC) Powder at a competitive price. The purity and particle size can be tailored according to specific requirements.

More details

Inquiry

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Data sheet

Purity99.0% - 99.9%
CAS12070-06-3
Molecular FormulaTaC

More info

Tantalum Carbide (TaC) Powder is an important cermet material, which has high chemical stability. It is insoluble in water and indissoluble in inorganic acids. However, it is soluble in a mixture of hydrofluoric acid and nitric acid and decomposable.

Tantalum Carbide Powder, TaC, CAS 12070-06-3

  • Formula: TaC
  • Melting point: 3880℃
  • Boiling point: 5500℃
  • Density: 14.3 g/cm3
  • Molecular weight: 192.96 g/mol
  • CAS: 12070-06-3

Tantalum Carbide Powder Chemical Analysis

Product

Particle Size FSSS (μm)

Chemical Composition (%)

Total Carbon

Free Carbon

Impurity (%max)

Nb

Fe

Si

Al

Ti

O

N

Na

Ca

HM-TaC-1

0.6-0.8

6.2±0.2

≤0.15

0.1

0.05

0.01

0.005

0.01

0.40

0.2

0.005

0.01

HM-TaC-2

0.8-1.0

6.2±0.2

≤0.15

0.1

0.05

0.01

0.005

0.01

0.30

0.2

0.005

0.01

HM-TaC-3

1.0-1.5

6.2±0.2

≤0.15

0.1

0.05

0.01

0.005

0.01

0.20

0.2

0.005

0.01

HM-TaC-4

1.5-2.0

6.2±0.2

≤0.15

0.1

0.05

0.01

0.005

0.01

0.15

0.2

0.005

0.01

Tantalum Carbide Powder Properties

Tantalum Carbide (TaC) Powder has high resistance to oxidation and high electrical conductivity.

Tantalum Carbide Powder, TaC, CAS 12070-06-3

  • The highest purity is 99.99%
  • Small particle size: min30-50nm
  • Concentrated distribution
  • Typical product: D10≥1.0μm, D50 1.2~1.8μm, D90≤3.0μm

Tantalum Carbide Powder Applications

  • Used in powder metallurgy
  • Used as a hard coating in cutting tools, hard wear-resistant alloy tools, molds
  • Used in fine ceramics
  • Used in chemical vapor deposition
  • Used as additives for wear and corrosion-resistant structural parts

Tantalum Carbide Powder Storage and Packing

Tantalum Carbide (TaC) Powder should be sealed and stored in a dry, cool environment, and not be exposed to the air for a long time, using inert anti-static packaging. The vacuum packing is 100g, 500g, 1kg/bag, 25kg/drum, or as required.
