SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder

Reference: SP-1820

Condition: New product

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder is an alloy powder composed of tin (Sn), silver (Ag), and copper (Cu), which is widely used in various soldering applications. The average particle size is 0.5-2um. We can also customize the ratio of the element contents and particle size according to customers' requirements.

More details

Inquiry

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Data sheet

Particle Size	0.5-2μm, or customized
Molecular Formula	Sn-0.3Ag-0.7Cu, Sn-3.0Ag-0.5Cu

More info

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder provides reliable solder joints with good wetting characteristics, ensuring proper electrical and mechanical connections. Heeger Materials (HM) can provide high-quality SAC series Spherical Lead-Free Alloy Powder at a competitive price.

SAC (Sn-Cu-Ag) Spherical Lead-Free Solder Powder

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder Specifications

Product	Average Particle Size (μm)	Melting Point (℃)	Chemical Composition (wt%)
HM-SAC0307	1.00-2.00	224-226	Sn-0.3Ag-0.7Cu
HM-SAC305	1.00-2.00	217-219	Sn-3.0Ag-0.5Cu

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder Properties

SAC305 (Sn-3.0Ag-0.5Cu) Spherical Lead-Free Solder Powder SEM

High powder sphericity
Uniform particle size
Good dispersibility
Low oxygen content

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder Applications

Used for surface mount.
Used in semiconductor packaging and other processes.

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder Storage and Packing

SAC (Sn-Ag-Cu) Spherical Lead-Free Solder Powder should be stored in a sealed container in a dry and cool place, and should not be exposed to air for an extended period of time. We offer vacuum-sealed packaging options including 100g/bag, 500g/bag, 1kg/bag, and 25kg/drum, or we can provide customized packaging as per your specific requirements.
