BN-BO, B2O3-bonded Boron Nitride Ceramic - Grade A
HM1313
New product
Boron Nitride + Boric Oxide (BN+B2O3) Ceramic, also known as BN-BO, is crafted from BN and B2O3, representing the industry's primary option for high-temperature insulation. Heeger Materials offers high-quality Boron Nitride Ceramic (BN-BO) at competitive prices, featuring high purity and precise dimensional tolerance.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Data sheet
| Materials | BN+B2O3 |
| Size | Per request or drawing |
More info
99 Boron Nitride (BN): Boron Nitride + Boric Oxide (B2O3) Ceramic is manufactured using BN and B2O3. BN-BO employs a B2O3 binder to enhance the mechanical strength of hot-pressed hBN, rendering it the go-to option for high-temperature insulation in the industry.
- High-density, high-purity powder is a practical choice for high-temperature insulators.
- It is the best choice for special nozzles and nozzles.
- Excellent processing performance can be achieved according to any drawing.
BN-BO, B2O3-bonded Boron Nitride Ceramic - Grade A Selection Notes
BN-BO, B2O3-bonded Boron Nitride Ceramic - Grade A belongs to the boron nitride products range and is selected for thermal stability, machinability, electrical insulation and chemical resistance. It is commonly used in project-specific assemblies, prototypes, replacement parts and drawing-based ceramic components as well as vacuum furnaces, molten metal handling, semiconductor fixtures, nozzles and high-temperature insulation. When requesting a quote, confirm drawings, dimensions, tolerances, material grade, surface finish, quantity and working environment.
Related Materials and Product Forms
For material comparison or adjacent product forms, browse BN plates and sheets, BN crucibles, technical ceramics and boron nitride products.
FAQ
Can BN-BO, B2O3-bonded Boron Nitride Ceramic - Grade A be customized? Yes. Heeger Materials can review custom sizes, purity or grade requirements, tolerances, drawings, quantities and application conditions for this product.
Composite BN-BO Ceramic Specifications
| Grade | BN-Bo |
| Compositions | BN>98% |
| Binder | B2O3 |
| Density | 2.1-2.2 g/cm3 |
| 25°C Volume Resistivity | >10^13 Ω·cm |
| Max. Service Temp. (°C) | 900 (Oxygen) |
| 2000 (Inert Gas) | |
| 1800 (High Vacuum) | |
| Flexural Strength | 75 Mpa |
| Compressive Strength | 100 Mpa |
| Coefficient of Thermal Expansion (25-1000°C) | 2.0 10^-6/K |
| Thermal Conductivity | 30 W/mK |
*Due to the hygroscopic adhesive system, BN-BO must be wont to avoid exposure to moisture.
Boron Nitride Material Basic Properties
Grade |
| HM-BN-H | HM-BN-99 | HM-BN-T | HM-BN-N | HM-BN-S | |||
Main ingredients |
| BN>99.7% | BN>99% | BN+TiB2+AlN | BN+ZrO2+SiC | BN+ZrO2+SiC | BN+AlN | BN+Si3N4 | BN+SiO2 |
Density | g/cm3 | 1.50- 1.60 | 1.95-2.05 | 3.01 | 2.3-2.35 | 2.6-2.7 | 2.8-2.9 | 2.5-2.6 | 2.1-2.15 |
Hardness | HL | - | - | - | 570-620 | 520-550 | ≥650 | 650-680 | 700-750 |
Flexural Strength | Mpa | 95 | 35 | 155 | 160 | 150 | 250-300 | 280 | 75 |
Coefficient of thermal expansion | (10-6/K) | 1.5 | 1.8 | 6.0-7.0 | 2.0-3.0 | 3.0-5.0 | 4.0-5.0 | 2.5-3.0 | 2.5-3.0 |
Thermal conductivity at 20 ℃ | W/mk | 35 | 35 | 40 | 15 | 30 | 65 | 45 | 20 |
MAX-Temperature of use | oxidizing | 900℃ | 900℃ | 950℃ | 900℃ | 900℃ | 950℃ | 950℃ | 1000℃+ |
insert | 1900℃
| 1900℃
| 2000℃ | 1700℃ | 1700℃ | 2000℃ | 1700℃ | 1000℃+ | |
RT Resistivity | Ω·cm | >1014 | >1014 | 250-1000 u | >1012 | >1012 | >1014 | >1014 | >1014
|
Composite BN-BO Ceramic Applications
- As a blowing nozzle
- Applied in ion implanters.
- Suitable for the electronics industry, constantly looking for new applications.
Hexagonal Boron Nitride Materials Types
- Pyrolytic boron nitride PBN: 99.99% boron nitride
- High purity boron nitride HPBN: >98.5% boron nitride + boron oxide
- Calcium Borate Boron Nitride CABN: >97.5% Boron Nitride + Calcium Borate
- Aluminum Nitride Boron Nitride ALBN: Boron Nitride + Aluminum Nitride + Boron Aluminum Oxide
- Zirconia Boron Nitride ZRBN: Boron Nitride + Zirconia + Boron Oxide
- Zirconium Aluminum Boron Nitride ZABN: Boron Nitride + Zirconia + Aluminum Nitride + Aluminum Boron Oxide
- Silicon carbide boron nitride SCBN: boron nitride + silicon carbide + boron silicon oxide
Composite BN-BO Ceramic Packing
HM's Boron Nitride Composite Ceramic (BN-BO) products are carefully packaged in carton boxes with foam protection to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Where to Buy Composite BN-BO Ceramic in Bulk?
Heeger Materials Inc., a professional supplier and manufacturer of high-quality Boron Nitride (BN) Ceramic products, including Composite BN-BO Ceramic, leverages extensive expertise in supply and export to offer competitive prices. We provide customized solutions to meet specific requirements, ensuring exceptional quality and customer satisfaction.
