Zirconium Nitride Powder, ZrN, CAS 25658-42-8
HMNP-1672
New product
Zirconium Nitride (ZrN) Powder is a hard ceramic, refractory, inorganic compound. It is used as a coating on medical devices, drill bits, and high-wear automotive and aerospace parts. The purity and particle size can be tailored according to specific requirements.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Data sheet
| Purity | ＞99.9% |
| CAS | 25658-42-8 |
| Molecular Formula | ZrN |
More info
Zirconium Nitride (ZrN) Powder has very good physical and chemical stability, high hardness, high melting point, high-temperature resistance, corrosion resistance, and wear resistance. HM provides high-quality Zirconium Nitride (ZrN) Powder at a competitive price, which can be used in manufacturing hot pressing crucibles, refining metal aluminum, bismuth, cadmium, lead, and tin.
- Formula: ZrN
- Purity: ＞99.9%
- Molecular Weight: 105.23
- Density: 7.09g/cm3
- Volume Density: 3.20g/m³
- Melting Point: 2980℃
- Microhardness: 9.8~19.6GPa
- Moh's hardness: 8~9
- Average grain Size: 500nm
- Specific surface area: 33.10m²/g
- CAS: 25658-42-8
Zirconium Nitride Powder Chemical Analysis
Product | Purity (%) | Particle D50 (μm） | Impurity (ppm) | |||||||||
Al | Ca | Mg | Cu | Mn | Na | Co | Ni | Si | Pb | |||
HM-ZrN-1 | 99.99 | ＜2 | 10 | 5 | 10 | 5 | 5 | 10 | 8 | 5 | 10 | 2 |
HM-ZrN-2 | 99 | ＜10 | 15 | 10 | 10 | 10 | 10 | 20 | 8 | 5 | 15 | 5 |
Zirconium Nitride Powder Properties
- High purity: 99%~99.99%
- Small particle size: min50-100nm
- Concentrated distribution
- Typical products: 1-3μm, 10-60μm
Zirconium Nitride Powder Applications
- Thermal wear-resistant materials
- Corrosion-resistant material
- High-temperature ceramic conductive materials
- High-resistance film resistors
- In the jewelry industry for decorative films
- Nanocomposite hard tools, carbide
- Copper-silicon contact diffusion barrier in the semiconductor industry
- Dispersion-reinforced material
- Protective layer alloy material
Zirconium Nitride Powder Storage and Packing
Zirconium Nitride (ZrN) Powder should be sealed and kept in a dry and cool environment, and should not be exposed to air for a long time to prevent moisture agglomeration, which will affect the dispersion performance and use effect, and should avoid heavy pressure and contact with oxidant, and be transported according to general cargo. The vacuum packing is 100g, 500g, 1kg/bag, 25kg/barrel, or as required.
