Zirconium Nitride Powder, ZrN, CAS 25658-42-8

HMNP-1672

New product

Zirconium Nitride (ZrN) Powder is a hard ceramic, refractory, inorganic compound. It is used as a coating on medical devices, drill bits, and high-wear automotive and aerospace parts. The purity and particle size can be tailored according to specific requirements.

More details

Inquiry

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Data sheet

Purity>99.9%
CAS25658-42-8
Molecular FormulaZrN

More info

Zirconium Nitride (ZrN) Powder has very good physical and chemical stability, high hardness, high melting point, high-temperature resistance, corrosion resistance, and wear resistance. HM provides high-quality Zirconium Nitride (ZrN) Powder at a competitive price, which can be used in manufacturing hot pressing crucibles, refining metal aluminum, bismuth, cadmium, lead, and tin.

Zirconium Nitride Powder, ZrN, CAS 25658-42-8

  • Formula: ZrN
  • Purity: >99.9%
  • Molecular Weight: 105.23
  • Density: 7.09g/cm3
  • Volume Density: 3.20g/m³
  • Melting Point: 2980℃
  • Microhardness: 9.8~19.6GPa
  • Moh's hardness: 8~9
  • Average grain Size: 500nm
  • Specific surface area: 33.10m²/g
  • CAS: 25658-42-8

Zirconium Nitride Powder Chemical Analysis

Product

Purity (%)

Particle D50 (μm)

Impurity (ppm)

Al

Ca

Mg

Cu

Mn

Na

Co

Ni

Si

Pb

HM-ZrN-1

99.99

<2

10

5

10

5

5

10

8

5

10

2

HM-ZrN-2

99

<10

15

10

10

10

10

20

8

5

15

5

Zirconium Nitride Powder Properties

Zirconium Nitride Powder, ZrN, CAS 25658-42-8 SEM

  • High purity:  99%~99.99%
  • Small particle size: min50-100nm
  • Concentrated distribution
  • Typical products: 1-3μm, 10-60μm

Zirconium Nitride Powder Applications

  • Thermal wear-resistant materials
  • Corrosion-resistant material
  • High-temperature ceramic conductive materials
  • High-resistance film resistors
  • In the jewelry industry for decorative films
  • Nanocomposite hard tools, carbide
  • Copper-silicon contact diffusion barrier in the semiconductor industry
  • Dispersion-reinforced material
  • Protective layer alloy material

Zirconium Nitride Powder Storage and Packing

Zirconium Nitride (ZrN) Powder should be sealed and kept in a dry and cool environment, and should not be exposed to air for a long time to prevent moisture agglomeration, which will affect the dispersion performance and use effect, and should avoid heavy pressure and contact with oxidant, and be transported according to general cargo. The vacuum packing is 100g, 500g, 1kg/bag, 25kg/barrel, or as required.
